Oil scales
Own production
Appointment
Scales are designed to measure the mass of liquid products entering the hopper and to take into account the total amount of product that has passed through it. The scales allow you to control the process of oil metering and metering in production or technological lines.
Characteristic
They operate in continuous weighing mode and automatically weigh the product entering the hopper. The current and total weight, the set portion size, as well as the number of weighted portions of the product are displayed on the display module screen. The weighing accuracy is 0.1-0.2%.
Scales combine high precision, functionality, automation and reliability, which makes them the optimal choice for industrial tasks related to the control and accounting of liquid products.
Operating conditions
The operating temperature range is from 0 to plus 40 °C.
Relative humidity is 65±15%.
Atmospheric pressure ranges from 84 to 106 kPa or from 630 to 800 mmHg..
In terms of resistance to climatic influences, the scales comply with the performance of UHL category 4.2 according to GOST 15150.
The scales are not intended for use in explosive and fire-hazardous areas, as well as in conditions of exposure to aggressive environments.
Technical data
|
Naming of the indicator |
Meaning |
| Maximum weighing limit, NIP, kg |
300 |
|
The lowest weighing limit, NMV, kg |
2 |
| The discreteness of the display (d) and the price of the verification division (e), kg |
0,1 |
|
Static weighing error during certification (during operation), kg,:* From 50 to 100 St. 100 |
±0,05 (±0,1) ±0,1 (±0,2) |
| Accuracy class | Average (III) |
| Maximum productivity, t/h |
Defined by calculated or experimentally in the process operation |
| Operating temperature range of load cells |
-30…+40 °С |
| Operating temperature range of the weighing transducer |
0…+40 °С |
| The degree of protection of strain gauges according to GOST is not worse |
IP 65 |
| Electrical power supply parameters of the scale |
230 (±10) В, 50 (±1) Гц |
| The time when the scale is ready for operation after switching on, min |
10 |
| Overall dimensions (width x length x height), m |
900х900х1500 |
| Weight not more than, kg |
350 |
The principle of operation
The principle of operation of the scales in the flow is based on cyclic weighing of portions of the product in a weighing hopper with summation of the mass of each plumb line with continuous feeding of the material into the storage tank, which ensures high accuracy of the result.
The principle of operation of the weighing device is based on the transformation of the deformation of the elastic element of the strain gauge sensor, which occurs under the influence of the weighed load when installed on the load receiving device, into an analog electrical signal; the conversion of an analog signal into a digital form in a discrete counting device, followed by digital processing by a microprocessor and the output of the result.
Advantages
Scales have a number of advantages and advantages that make them an effective solution for industrial tasks.
- Weighing accuracy
- Infinite outweighing of the product flow with maximum productivity (can operate in continuous weighing mode)
- Maintaining a set average overweight capacity (the system allows you to adjust the feed rate of the product)
- Process automation
- The scales display on the display module screen: the current and total weight; the set portion size; the number of weighted portions of the product.
- Wide operating temperature range - from 0 to +40 °C.
- The degree of protection of the control cabinet is IP54 according to GOST 14254
MANUFACTURER: Globalprodservice
Hopper scales are designed to measure the mass of liquid products entering the hopper and to take into account the total amount of product that has passed through it. The scales allow you to control the process of oil metering and metering in production or processing lines.
They operate in continuous weighing mode and automatically weigh the product entering the hopper. The current and total weight, the set portion size, as well as the number of weighted portions of the product are displayed on the display module screen. The weighing accuracy is 0.1-0.2%.
Hopper scales combine high precision, functionality, automation and reliability, which makes them the optimal choice for industrial tasks related to the control and accounting of liquid products.
|
Naming of the indicator |
Meaning |
| Maximum weighing limit, NIP, kg |
300 |
|
The lowest weighing limit, NMV, kg |
2 |
| The discreteness of the display (d) and the price of the verification division (e), kg |
0,1 |
|
Static weighing error during certification (during operation), kg,:* From 50 to 100 St. 100 |
±0,05 (±0,1) ±0,1 (±0,2) |
| Accuracy class | Average (III) |
| Maximum productivity, t/h |
Defined by calculated or experimentally in the process operation |
| Operating temperature range of load cells |
-30…+40 °С |
| Operating temperature range of the weighing transducer |
0…+40 °С |
| The degree of protection of strain gauges according to GOST is not worse |
IP 65 |
| Electrical power supply parameters of the scale |
230 (±10) В, 50 (±1) Гц |
| The time when the scale is ready for operation after switching on, min |
10 |
| Overall dimensions (width x length x height), m |
900х900х1500 |
| Weight not more than, kg |
350 |
The operating temperature range is from 0 to plus 40 °C.
Relative humidity is 65±15%.
Atmospheric pressure ranges from 84 to 106 kPa or from 630 to 800 mmHg..
In terms of resistance to climatic influences, the scales comply with the performance of UHL category 4.2 according to GOST 15150.
The scales are not intended for use in explosive and fire-hazardous areas, as well as in conditions of exposure to aggressive environments.
The principle of operation of the scales in the flow is based on cyclic weighing of portions of the product in a weighing hopper with summation of the mass of each plumb line with continuous feeding of the material into the storage tank, which ensures high accuracy of the result.
The principle of operation of the weighing device is based on the transformation of the deformation of the elastic element of the strain gauge sensor, which occurs under the influence of the weighed load when installed on the load receiving device, into an analog electrical signal; the conversion of an analog signal into a digital form in a discrete counting device, followed by digital processing by a microprocessor and the output of the result.
Scales have a number of advantages and advantages that make them an effective solution for industrial tasks.
- Weighing accuracy
- Infinite outweighing of the product flow with maximum productivity (can operate in continuous weighing mode)
- Maintaining a set average overweight capacity (the system allows you to adjust the feed rate of the product)
- Process automation
- The scales display on the display module screen: the current and total weight; the set portion size; the number of weighted portions of the product.
- Wide operating temperature range - from 0 to +40 °C.
- The degree of protection of the control cabinet is IP54 according to GOST 14254
MANUFACTURER: Globalprodservice
